SLURM

SLURM (Simple Linux Utility for Resource Management)¹ is an open-source job scheduler that handles the allocation of resources in a compute cluster. It is commonly used in HPC (High Performance Computing) environments. WATcloud uses SLURM to manage most of its compute resources.

This page provides an introduction to SLURM and any WATcloud-specific details² to get you started quickly. For more advanced usage beyond the basics, please refer to the official SLURM documentation (opens in a new tab).

Terminology

Before we dive into the details, let's define some common terms used in SLURM:

• SLURM Login node: A node that users log into to submit jobs to the SLURM cluster. This is where you will interact with the SLURM cluster.
• SLURM Compute node: A node that runs jobs submitted to the SLURM cluster. This is where your job will run.
• Partition: A logical grouping of nodes in the SLURM cluster. Partitions can have different properties (e.g. different resource limits) and are used to organize resources.
• Job: A unit of work submitted to the SLURM cluster. A job can be interactive or batch.
• Interactive job: A job that runs interactively on a compute node. This is useful for debugging or running short tasks.
• Batch job: A job that runs non-interactively on a compute node. This is useful for running long-running tasks like simulations or ML training.
• Job array: A collection of jobs with similar parameters. This is useful for running parameter sweeps or other tasks that require running the same job multiple times with potentially different inputs.
• Resource: A physical or logical entity that can be allocated to a job. Examples include CPUs, memory, GPUs, and temporary disk space.
• GRES (Generic Resource): A SLURM feature that allows for arbitrary resources to be allocated to jobs. Examples include GPUs and temporary disk space.

Quick Start

SSH into a SLURM login node

To submit jobs to the SLURM cluster, you must first SSH into one of the SLURM login nodes³:

• tr-ubuntu3
• derek3-ubuntu2

Instructions on how to SSH into machines can be found here.

Interactive shell

Once SSHed into a SLURM login node, you can execute the following command to submit a simple job to the SLURM cluster:

srun --pty bash

This will start an interactive shell session on a compute node with the default resources. You can view the resources allocated to your job by running:

scontrol show job $SLURM_JOB_ID

An example output is shown below:

JobId=1305 JobName=bash
   UserId=ben(1507) GroupId=ben(1507) MCS_label=N/A
   Priority=1 Nice=0 Account=watonomous-watcloud QOS=normal
   JobState=RUNNING Reason=None Dependency=(null)
   Requeue=1 Restarts=0 BatchFlag=0 Reboot=0 ExitCode=0:0
   RunTime=00:00:04 TimeLimit=00:30:00 TimeMin=N/A
   SubmitTime=2024-03-16T06:39:57 EligibleTime=2024-03-16T06:39:57
   AccrueTime=Unknown
   StartTime=2024-03-16T06:39:57 EndTime=2024-03-16T07:09:57 Deadline=N/A
   SuspendTime=None SecsPreSuspend=0 LastSchedEval=2024-03-16T06:39:57 Scheduler=Main
   Partition=compute AllocNode:Sid=10.1.100.128:1060621
   ReqNodeList=(null) ExcNodeList=(null)
   NodeList=wato2-slurm1
   BatchHost=wato2-slurm1
   NumNodes=1 NumCPUs=1 NumTasks=1 CPUs/Task=1 ReqB:S:C:T=0:0:*:*
   ReqTRES=cpu=1,mem=512M,node=1,billing=1,gres/tmpdisk=100
   AllocTRES=cpu=1,mem=512M,node=1,billing=1,gres/tmpdisk=100
   Socks/Node=* NtasksPerN:B:S:C=0:0:*:* CoreSpec=*
   MinCPUsNode=1 MinMemoryCPU=512M MinTmpDiskNode=0
   Features=(null) DelayBoot=00:00:00
   OverSubscribe=OK Contiguous=0 Licenses=(null) Network=(null)
   Command=bash
   WorkDir=/home/ben
   Power=
   TresPerNode=gres/tmpdisk:100

In this example, the job is allocated 1 CPU, 512MiB of memory, and 100MiB of temporary disk space (mounted at /tmp), and is allowed to run for up to 30 minutes.

To request for more resources, you can use the --cpus-per-task, --mem, --gres, and --time flags. For example, to request 4 CPUs, 4GiB of memory, 20GiB of temporary disk space, and 2 hours of running time, you can run:

srun --cpus-per-task 4 --mem 4G --gres tmpdisk:20480 --time 2:00:00 --pty bash

Note that the amount of requestable resources is limited by the resources available on the partition/node you are running on. You can view the available resources by referring to the View available resources section.

Cancelling a job

To cancel a job, you can use the scancel command. You will need the job ID to cancel a job. You can find the job ID by running squeue. If you are in a job, you can also use the $SLURM_JOB_ID environment variable.

For example, you can see a list of your jobs by running:

squeue -u $(whoami)

Example output:

JOBID PARTITION     NAME     USER ST       TIME  NODES NODELIST(REASON)
4022   compute     bash      ben  R       0:03      1 thor-slurm1

To cancel the job with ID 4022, you can run:

scancel 4022

Using Docker

Unlike general use machines, the SLURM environment does not provide user-space systemd for managing background processes like the Docker daemon. To use Docker, you will need to start the Docker daemon manually. We have provided a convenience script to do this:

slurm-start-dockerd.sh

If successful, you should see the following output:

Dockerd started successfully!

Test it with:
docker run --rm hello-world

Note that slurm-start-dockerd.sh places the Docker data directory in /tmp. You can request for more space using the --gres tmpdisk:<size_in_MiB> flag.

Using GPUs

You can request access to GPUs by using the --gres shard:<size_in_MiB> flag. For example, if your workload requires 4 GiB of VRAM, you can run:

srun --gres shard:4096 --pty bash

Your job will be allocated a GPU with at least 4 GiB of unreserved VRAM. Please note that the amount of VRAM requested is not enforced, and you should ensure that the amount requested is appropriate for your workload.

Using shard is the preferred way to request for GPU resources because it allows multiple jobs to share the same GPU.

It's common to request extra tmpdisk space along with GPUs. To do this, you can append ,tmpdisk:<size_in_MiB> to the --gres flag. For example:

srun --gres shard:4096,tmpdisk:20480 --pty bash

If your workload requires exclusive access to a GPU, you can use the --gres gpu flag instead:

srun --gres gpu:1 --pty bash

This will allocate a whole GPU to your job. Note that this will prevent other jobs from using the GPU until your job is finished.

Using CUDA

If your workload requires CUDA, you have a few options (not exhaustive):

Using the nvidia/cuda Docker image

You can use the nvidia/cuda Docker image to run CUDA workloads. Assuming you have started the Docker daemon (see Using Docker), you can run the following command to start a CUDA container:

docker run --rm -it --gpus all -v $(pwd):/workspace nvidia/cuda:12.0.0-devel-ubuntu22.04 nvcc --version

Note that the version of the Docker image must be compatible with (usually this means lower than or equal to) the driver version installed on the compute node. You can check the driver version by running nvidia-smi. If the driver version is not compatible with the Docker image, you will get an error that looks like this:

> docker run --rm -it --gpus all -v $(pwd):/workspace nvidia/cuda:12.1.0-runtime-ubuntu22.04
docker: Error response from daemon: failed to create task for container: failed to create shim task: OCI runtime create failed: runc create failed: unable to start container process: error during container init: error running hook #0: error running hook: exit status 1, stdout: , stderr: Auto-detected mode as 'legacy'
nvidia-container-cli: requirement error: unsatisfied condition: cuda>=12.1, please update your driver to a newer version, or use an earlier cuda container: unknown.

Using the Compute Canada CUDA module

The Compute Canada CVMFS⁴ is mounted on the compute nodes. You can access CUDA by loading the appropriate module:

# Set up the module environment
source /cvmfs/soft.computecanada.ca/config/profile/bash.sh
# Load the appropriate environment
module load StdEnv/2023
# Load the CUDA module
module load cuda/12.2
# Check the nvcc version
nvcc --version

Compute Canada only provides select versions of CUDA, and does not provide an easy way to list all available versions. A trick you can use is to run which nvcc and trace back along the directory tree to find sibling directories that contain other CUDA versions.

Note that the version of CUDA must be compatible with the driver version installed on the compute node. You can check the driver version by running nvidia-smi. You can find the CUDA compatibility matrix here (opens in a new tab).

Batch jobs

The real power of SLURM comes from batch jobs. Batch jobs are non-interactive jobs that start automatically when resources are available and release the resources when the job is finished. This helps to maximize resource utilization and allows you to easily run large numbers of jobs (e.g. parameter sweeps).

To submit a batch job, create a script that looks like this:

#!/bin/bash
#SBATCH --job-name=my_job
#SBATCH --cpus-per-task=1
#SBATCH --mem=1G
#SBATCH --gres tmpdisk:1024
#SBATCH --time=00:10:00
#SBATCH --output=logs/%j-%x.out  # %j: job ID, %x: job name. Reference: https://slurm.schedmd.com/sbatch.html#lbAH

echo "Hello, world! I'm running on $(hostname)"
echo "Counting to 60..."
for i in $(seq 60); do
    echo $i
    sleep 1
done
echo "Done!"

The #SBATCH lines are SLURM directives that specify the resources required by the job⁵. They are the same as the flags you would pass to srun.

To submit the job, run:

sbatch slurm_job.sh

This submits the job to the SLURM cluster, and you will receive a job ID in return. After the job is submitted, it will be queued until resources are available.

You can see a list of your queued and in-progress jobs by running⁶:

squeue -u $(whoami) --format="%.18i %.9P %.30j %.20u %.10T %.10M %.9l %.6D %R"

After the job starts, the output of the job is written to the file specified in the --output directive. In the example above, you can view the output of the job by running:

tail -f logs/*-my_job.out

After the job finishes, it disappears from the queue. You can retrieve useful information about the job (exit status, running time, etc.) by running⁷:

sacct --format=JobID,JobName,State,ExitCode

Job arrays

Job arrays are a way to submit multiple jobs with similar parameters. This is useful for running parameter sweeps or other tasks that require running the same job multiple times with potentially different inputs.

To submit a job array, create a script that looks like this:

#!/bin/bash
#SBATCH --job-name=my_job_array
#SBATCH --cpus-per-task=1
#SBATCH --mem=1G
#SBATCH --gres tmpdisk:1024
#SBATCH --time=00:10:00
#SBATCH --output=logs/%A-%a-%x.out # %A: job array master job allocation number, %a: Job array index, %x: job name. Reference: https://slurm.schedmd.com/sbatch.html#lbAH
#SBATCH --array=1-10

echo "Hello, world! I'm job $SLURM_ARRAY_TASK_ID, running on $(hostname)"
echo "Counting to 60..."
for i in $(seq 60); do
    echo $i
    sleep 1
done
echo "Done!"

The --array directive specifies the range of the job array (in this case, from 1 to 10, inclusive).

To submit the job array, run:

sbatch slurm_job_array.sh

This will submit 10 jobs with IDs ranging from 1 to 10. You can view the status of the job array by running:

squeue -u $(whoami) --format="%.18i %.9P %.30j %.20u %.10T %.10M %.9l %.6D %R"

After jobs in the array start, the output of each job is written to a file specified in the --output directive. In the example above, you can view the output of each job by running:

tail -f logs/*-my_job_array.out

To learn more about job arrays, including environment variables available to job array scripts, see the official documentation (opens in a new tab).

Long-running jobs

Each job submitted to the SLURM cluster has a time limit. The time limit can be set using the --time directive. The maximum time limit is determined by the partition you are running on. You can view a list of partitions, including the default partition, by running sinfo⁸:

> sinfo
PARTITION     AVAIL  TIMELIMIT  NODES  STATE NODELIST
compute*         up 1-00:00:00      5   idle thor-slurm1,tr-slurm1,trpro-slurm[1-2],wato2-slurm1
compute_dense    up 7-00:00:00      5   idle thor-slurm1,tr-slurm1,trpro-slurm[1-2],wato2-slurm1

In the output above, the cluster has 2 partitions, compute (default) and compute_dense, with time limits of 1 day and 7 days, respectively. If your job requires more than the maximum time limit for the default partition, you can specify a different partition using the --partition flag. For example:

#!/bin/bash
#SBATCH --job-name=my_dense_job
#SBATCH --cpus-per-task=1
#SBATCH --mem=1G
#SBATCH --gres tmpdisk:1024
#SBATCH --partition=compute_dense
#SBATCH --time=2-00:00:00
#SBATCH --output=logs/%j-%x.out  # %j: job ID, %x: job name. Reference: https://slurm.schedmd.com/sbatch.html#lbAH

echo "Hello, world! I'm allowed to run for 2 days!"
for i in $(seq $((60*60*24*2))); do
    echo $i
    sleep 1
done
echo "Done!"

If you require a time limit greater than the maximum time limit for any partition, please contact the WATcloud team to request an exception.

Extra details

SLURM v.s. general-use machines

The SLURM environment is configured to be as close to the general-use environment as possible. All of the same network drives and software are available. However, there are some differences:

• The SLURM environment uses a /tmp drive for temporary storage instead of /mnt/scratch on general-use machines. Temporary storage can be requested using the --gres tmpdisk:<size_in_MiB> flag.
• The SLURM environment does not have a user-space systemd for managing background processes like the Docker daemon. Please follow the instructions in the Using Docker section to start the Docker daemon.

View available resources

There are a few ways to view the available resources on the SLURM cluster:

View a summary of available resources

sinfo

Example output:

PARTITION     AVAIL  TIMELIMIT  NODES  STATE NODELIST
compute*         up 1-00:00:00      5   idle thor-slurm1,tr-slurm1,trpro-slurm[1-2],wato2-slurm1
compute_dense    up 7-00:00:00      5   idle thor-slurm1,tr-slurm1,trpro-slurm[1-2],wato2-slurm1

View available partitions

scontrol show partitions

Example output:

PartitionName=compute
   AllowGroups=ALL AllowAccounts=ALL AllowQos=ALL
   AllocNodes=ALL Default=YES QoS=N/A
   DefaultTime=00:30:00 DisableRootJobs=NO ExclusiveUser=NO GraceTime=0 Hidden=NO
   MaxNodes=UNLIMITED MaxTime=1-00:00:00 MinNodes=0 LLN=NO MaxCPUsPerNode=UNLIMITED MaxCPUsPerSocket=UNLIMITED
   Nodes=thor-slurm1,tr-slurm1,trpro-slurm[1-2],wato2-slurm1
   PriorityJobFactor=1 PriorityTier=1 RootOnly=NO ReqResv=NO OverSubscribe=NO
   OverTimeLimit=NONE PreemptMode=OFF
   State=UP TotalCPUs=240 TotalNodes=5 SelectTypeParameters=NONE
   JobDefaults=(null)
   DefMemPerNode=UNLIMITED MaxMemPerNode=UNLIMITED
   TRES=cpu=233,mem=707441M,node=5,billing=233,gres/gpu=10,gres/shard=216040,gres/tmpdisk=921600

PartitionName=compute_dense
   AllowGroups=ALL AllowAccounts=ALL AllowQos=ALL
   AllocNodes=ALL Default=NO QoS=N/A
   DefaultTime=00:30:00 DisableRootJobs=NO ExclusiveUser=NO GraceTime=0 Hidden=NO
   MaxNodes=UNLIMITED MaxTime=7-00:00:00 MinNodes=0 LLN=NO MaxCPUsPerNode=UNLIMITED MaxCPUsPerSocket=UNLIMITED
   Nodes=thor-slurm1,tr-slurm1,trpro-slurm[1-2],wato2-slurm1
   PriorityJobFactor=1 PriorityTier=1 RootOnly=NO ReqResv=NO OverSubscribe=NO
   OverTimeLimit=NONE PreemptMode=OFF
   State=UP TotalCPUs=240 TotalNodes=5 SelectTypeParameters=NONE
   JobDefaults=(null)
   DefMemPerNode=UNLIMITED MaxMemPerNode=UNLIMITED
   TRES=cpu=233,mem=707441M,node=5,billing=233,gres/gpu=10,gres/shard=216040,gres/tmpdisk=921600

View available nodes

scontrol show nodes

Example output:

NodeName=trpro-slurm1 Arch=x86_64 CoresPerSocket=1
   CPUAlloc=0 CPUEfctv=98 CPUTot=100 CPULoad=0.06
   AvailableFeatures=(null)
   ActiveFeatures=(null)
   Gres=gpu:rtx_3090:4(S:0),shard:rtx_3090:96K(S:0),tmpdisk:300K
   NodeAddr=trpro-slurm1.cluster.watonomous.ca NodeHostName=trpro-slurm1 Version=23.11.4
   OS=Linux 5.15.0-101-generic #111-Ubuntu SMP Tue Mar 5 20:16:58 UTC 2024
   RealMemory=423020 AllocMem=0 FreeMem=419161 Sockets=100 Boards=1
   CoreSpecCount=2 CPUSpecList=98-99 MemSpecLimit=2048
   State=IDLE ThreadsPerCore=1 TmpDisk=0 Weight=1 Owner=N/A MCS_label=N/A
   Partitions=compute
   BootTime=2024-03-24T00:17:08 SlurmdStartTime=2024-03-24T02:27:46
   LastBusyTime=2024-03-24T02:27:46 ResumeAfterTime=None
   CfgTRES=cpu=98,mem=423020M,billing=98,gres/gpu=4,gres/shard=98304,gres/tmpdisk=307200
   AllocTRES=
   CapWatts=n/a
   CurrentWatts=0 AveWatts=0
   ExtSensorsJoules=n/a ExtSensorsWatts=0 ExtSensorsTemp=n/a

...

In this example, the node trpro-slurm1 has the following allocable resources: 98 CPUs, around 413 GiB of RAM, 4 RTX 3090 GPUs, 98304 MiB of VRAM, and 300GiB of temporary disk space.

GRES

GRES (Generic Resource)⁹ is a SLURM feature that allows for arbitrary resources to be allocated to jobs. The WATcloud cluster provides the following GRES:

gres/tmpdisk

tmpdisk is a GRES that represents temporary disk space. This resource is provisioned using a combination of job_container/tmpfs¹⁰ and custom scripts. The temporary disk space is mounted at /tmp and is automatically cleaned up when the job finishes. You can request for temporary disk space using the --gres tmpdisk:<size_in_MiB> flag. Below is an example:

# Request 1 GiB of temporary disk space
srun --gres tmpdisk:1024 --pty bash

To see the total amount of temporary disk space available on a node, please refer to the View available resources section.

gres/shard and gres/gpu

shard and gpu are GRES that represent GPU resources. Allocation of these resources is managed by built-in SLURM plugins that interface with various GPU libraries.

The shard GRES is used to request access to a portion of a GPU. In the WATcloud cluster, the amount of allocable shard equals the amount of VRAM (in MiB) on each GPU. This representation is chosen because it is a concrete metric that works across different GPU models. The amount of resources requested using shard is not enforced, so please ensure that the shard requested is appropriate for your workload. To request for shard, use the --gres shard[:type]:<size_in_MiB>¹¹ flag, where type is optional and can be used to specify a specific GPU type. Below are some examples:

# Request 2 GiB of VRAM on any available GPU
srun --gres shard:2048 --pty bash

# Request 4 GiB of VRAM on an RTX 3090 GPU
srun --gres shard:rtx_3090:4096 --pty bash

To see a list of available GPU types, please refer to the View available resources section.

The gpu GRES is used to request exclusive access to GPUs¹². This is not recommended unless your workload can make efficient use of the entire GPU. If you are unsure, please use the shard GRES instead. To request for gpu, use the --gres gpu[:type]:<number_of_gpus> flag, where type is optional and can be used to specify a specific GPU type. Below are some examples:

# Request access to any available GPU
srun --gres gpu:1 --pty bash

# Request access to a whole RTX 3090 GPU
srun --gres gpu:rtx_3090:1 --pty bash

To see a list of available GPU types, please refer to the View available resources section.

Requesting multiple GRES

You can request multiple GRES by separating them with a comma. For example, to request 1 GiB of shard and 2 GiB of tmpdisk, you can run:

srun --gres shard:1024,tmpdisk:2048 --pty bash

CVMFS

CVMFS (CernVM File System)¹³ is a software distribution system that is widely adopted in the HPC community. It provides a way to distribute software to compute nodes without having to install them on the nodes themselves.

We make use of the Compute Canada CVMFS (opens in a new tab) to provide access to software available on Compute Canada clusters. For example, you can access CUDA by loading the appropriate module (see Using CUDA). A list of all availalbe modules can be found via the official documentation (opens in a new tab).

Troubleshooting

Invalid Account

You may encounter the following error when trying to submit a job:

srun: error: Unable to allocate resources: Invalid account or account/partition combination specified

This error usually occurs when your user does not have an associated account. You can verify this by running:

sacctmgr show user $(whoami)

If the output is empty (as shown below), then you do not have an associated account.

      User   Def Acct     Admin
---------- ---------- ---------

A common reason for this is that your WATcloud profile is not associated with a registered affiliation¹⁴. You can confirm this by requesting a copy of your profile using the Profile Editor and checking whether the general.affiliations field contains a registered affiliation. If your affiliation is not registered, please have your group lead fill out the registration form.
